Digital Output 2 Meters Range Strong Anti interference Pi Ultrasonic Sensor

Product Name
Liquid level Ultrasonic sensor

Highlight
Non contacted measuring, no need change the shape of container.
Wide voltage power input supported.
Small size, easy to install.
High frequency 2MHz ultrasonic detection, high solid penetration,suitable for various liquefied gas tanks.
Strong anti-interference, anti-static abilities
Real-time trace liquid level status, empty container no need restart.
Long measurement range, high accuracy 1mm.
RS485 output, quickly response.
Automatic output mode, not occupy hardware resources
Low power consumption.
Comes with temperature compensation.

Operating Voltage :10-36 v
Average Current :<30mA
Blind Area Distance :5 cm
Measuring Range :5-200cm
Accuracy :<5 mm
Resolution :<1 mm
Output Method :RS485
Frequency :2 MHz
Temperature Compensation :Yes

Chengdu Hao Li Electronic Technology Co., Ltd. is mainly engaged in the application design, development, production and sales of power supply and ultrasonic products. It has nearly 20 years of experience. It has in-depth cooperation with University of Electronic Science and Technology and Sichuan University. The products are mainly sold to Europe, the United States, Asia and other countries. The company has strong production capacity in power drive and intelligent control, application design of ultrasonic products, and can solve customization problems for customers.
