Short Distance Ultrasonic Proximity Switch With Temperature Compensation​

Description

Ultrasonic proximity switches are used to detect objects of different materials, shapes, colors, and concentrations, with excellent accuracy, flexibility, and reliability. Whether it is level measurement or height measurement, distance measurement or bottling counting, whether it is 2cm or 10m, various objects with different characteristics can be detected. It can be solid, liquid, powder, or even transparent objects. The detection is independent of the nature of the surface. The surface can be rough or smooth, clean or dirty, wet or dry. Rugged construction and insensitive to dirt, ambient light or noise.

Feature

• Ultrasonic sensor smooth detection surface
• Sealed cylindrical housing M18
• Connection via M12 x 1 connector
• Temperature compensation
• Blind area: 2.5cm
• Detection distance: 40cm
• Resolution 0.5mm
• Acoustic projection angle: 9°
• 1 × Switching quantityOutput, PNP
• Teachable setting
• Normally open / normally closed programmable

Specification
