EN55022 Class B 75W DC DC Switching Power Supply Universal AC Input / Full Range

Ask Lasest Price
Brand Name :	HAOLI
Certification :	CE，ISO9001，ROHS
Delivery Time :	10 work days
Price :	Negotiation

Add to Cart

Product Details
Company Profile

EN55022 Class B 75W DC DC Switching Power Supply Universal AC Input / Full Range

75W Single Output Industrial Power Supply

Product features

Universal AC input / full range
High efficiency up to 90%
Power on indication
Air cooling
Protection: Overload / Over voltage / Over temperature / Short circuit
150% peak load capability
100% full load burn-in test
3 years warranty

Specifications

Input voltage 88VAC~264VAC, 124VDC~370VDC

Input frequency 47HZ~63Hz

Inrush current 35A @ 230VAC full load cold start

Hold up time ≥20ms @ 230VAC full load

Overload protection 105%~150%

constant current limiting, auto-recovery

Over voltage protection 115%~135%

Operating temperature -25℃~70℃(refer to output load derating curve)

Safety standard EN60950-1, UL508

EMC standard EN55022 Class B,EN61000-6-2

Withstand voltage I/P-O/P: 3kVAC, 1min

I/P-FG: 1 5kVAC, 1min

O/P-FG: 0.5kVAC, 1min

Weight 0.36kg/pcs

Din-Rail type 480W Switching Power Supply(EDA Series)

Din-Rail type 480W Switching Power Supply(EDA Series) 480W Single Output Industrial Power Supply

FAQ

Q1: How many year warranty of your Led driver?
A: Three years
Q2: Do you have switch power factory?
A: Yes.We are OEM&ODM manufacturer in Chengdu
Q3: Do you offer sample of power?
A: Yes.We offer free sample ,but you need pay the shippment.
Q4: Is your power with copper transform or something?
A: We can do with complete copper transform and copper cladding aluminum.
Q5: Do you have any certification?
A: Yes.We have CE,ISO9001,ROHS,if you need other certification with large order,we can apply for it.

P/N	Output	Tol.	R&N	Effi.	Load Regulation	DC Adjustment Range
EDA-75-12	12V,6.3A	±2%	100mV	88%	±2%	12V~14V
EDA-75-24	24V,3.3A	±2%	120mV	89.5%	±2%	24V~28V
EDA-75-48	48V,1.56A	±2%	200mV	90%	±2%	48V~53V
