Specifications

Input voltage 85VAC~132VAC, 176VDC~264VDC

Input frequency 507HZ~60Hz

Inrush current 0.5A/115VAC,0.27A/230V

power factor ＞0.9

leakage current ＜1mA/240V
DC output voltage DC12V

DC Input Current 1A
Overload protection 180%~220% Cut off output, automatic recovery

Start, rise, hold time 200ms,50ms,20ms

AC Input voltage 0V~120V,0V~250V
Operating temperature -10℃~60℃,20%~90%RH

Resistant to high voltage 1500VAC/5mA/10s
Safety standard GB4943 UL60950 EN60950
Weight 469g

Size 160mm×100mm×42mm

OUR ADVANTAGES
OEM&ODM SERVICE
This company is engaged in the design,manufacture and sale of switching power series
LONG-TIME BURN-IN TEST

Each of the switch power is extremely safe and stable

FAQ
Q1: How many year warranty of your Led driver?
A: One years
Q2: Do you have switch power factory?
A: Yes.We are OEM&ODM manufacturer in Chengdu
Q3: Do you offer sample of power?
A: Yes.We offer free sample ,but you need pay the shippment.

Q4: Do you have any certification?
A: Yes.We have CE,ISO9001,ROHS,if you need other certification with large order,we can apply for it.
